Insize 0 - 20 MPa Digital Adhesion Tester, SPT-AD21

Shop all Insize

SKU: ME.NO.AD.00006

Model: SPT-AD21

Roll over image to zoom zoom_in
  1. Insize 0 - 20 MPa Digital Adhesion Tester, SPT-AD21
  2. Insize 0 - 20 MPa Digital Adhesion Tester, SPT-AD21

  • Weight: 3 Kg
  • Product Type: Adhesion Tester
  • Range (MPa): 0 - 20 MPa
  • Dolly Diameter: Ø20 mm
See all product information chevron_right
  • receiptGST Invoice
  • headphonesCustomer Service
  • lockSecure Payments
  • policyReturns & Warranty
  • home_pinOrder Tracking
  • paymentsBuy in Installments

171649.88 (Incl. of all taxes)

145466+ ₹26183.88 GST (18%)

MRP ₹255203

SAVE 43%



15 Business Days

1 Set

90248099

picture_as_pdfDownload Product Leafletkeyboard_double_arrow_right
picture_as_pdfBrand Authorization Certificatekeyboard_double_arrow_right
picture_as_pdfDownload Bosch Cataloguekeyboard_double_arrow_right

Highlights

  • Pull-off test
  • Built-in rechargeable lithium battery, no need external power source
  • Portable design, can be used anywhere
  • Standard USB interface, can directly transmit the stored data to computer, no need to install software
  • Conforms to GB/T 5210, ASTM D4541/D7234, ISO 4624/16276-1
  • Store all test results, includes maximum pull-off force, pull-off rate, dolly size and time
  • Built in real-time clock, all saved data have corresponding date and time
  • Selectable four different sizes dolly for different resolution and testing range
  • No need conversion, the instrument can calculate pull-off force according to the dolly size
  • Get the testing results from LCD directly
  • Two units MPa and psi for selection and can be converted automatically


Package Content:

Digital Adhesion Tester1 pc
Ø20 mm Dolly 20 pcs
Cutting Tool for Ø20 mm Dolly1 pc
Charger1 pc
USB Cable1 pc
Glue Gun1 pc
3M Glue1 pc

Once the Order is Placed, it can not be cancelled & Delivery time will be as per Stock Availiblity & it may take upto 25 days. Training & Installation will be charged extra if required.

Please Note that Product may differ eg. colour, size from the product Image displayed on website. Kindly check the specifications provided to make better purchase decision.

Specifications

SKUME.NO.AD.00006
Product TypeAdhesion Tester
Model NoSPT-AD21
Range (MPa) 0 - 20 MPa
Dolly Diameter Ø20 mm
Resolution 0.01MPa (1 psi)
Accuracy ±1% Full Scale
Pull-off Force 0.7 - 20MPa
Power Built-in Rechargeable Battery
Dimensions (L x W x H) 360 x 75 x 115 mm
