Insize ±0.9 mm Inductance Type Probe, 9420-AP02
Roll over the image to zoom in
Key Features
- Product Type: Probes & Accessories
- Weight: 16 g
- Range: ±0.9mm
- Accuracy: ±0.3+3× |L|3μm, (L is measuring length in mm)
- Sensor type: LVDT (full bridge)
ToolBuy Benefits
- Secure Payments
- Order Tracking (opens in a new tab)
₹20,347 (Incl. of all taxes)
₹17,243 + ₹3,104 GST (18%)
MRP was MRP ₹24,286
Save 29%
7 Business Days
1
90319000
Download Product LeafletNot available
Download Insize CatalogueNot available
Download Insize CatalogueNot available
Product Information
Highlights
- IP65 Waterproof
- Ultra-short length, built-in precision linear ball bearings
- For highly accurate and repeatable displacement measurements of displacement, deformation, dimension, vibration, thickness, expansion, etc. in quality control and metrology applications
Please Note that Products may differ eg. colour, size from the product Image displayed on website. Kindly check the specifications provided to make better purchase decision. M.R.P Prices and specifications are subject to change without notice.
Specifications
| Range | ±0.9mm |
|---|---|
| Accuracy | ±0.3+3× |L|3μm, (L is measuring length in mm) |
| Repeatability | 0.15μm |
| Thermal drift | 0.25μm/°C |
| Mechanical Stroke | 2.2 mm |
| Sensor type | LVDT (full bridge) |
| Measuring Force | 0.75N |
| Protective cover | Fluorinated elastomer |
| Contact Type | Carbide |
| Insert thread | M2.5 |
| Working Environment | -10 ~ 60°C, <80% (non-condensing) |
| Storage Temperature | -20 ~ 100°C, <80% (non-condensing) |
| Cable Length | 2m (Customised from 2 - 5m) |
| Output Interface | 5-wire aviation interface |
