Insize 2500mT AC/DC Teslameter (±2.0% DC), 0502-MC02
Roll over the image to zoom in
Key Features
- Product Type: Electro Magnetic Field Tester
- Weight: 350 g
- Range: 2500mT
- Accuracy: ±2.0% (DC) / ±5.0% (AC)
ToolBuy Benefits
- Secure Payments
- Order Tracking (opens in a new tab)
₹59,443 (Incl. of all taxes)
₹50,375 + ₹9,068 GST (18%)
MRP was MRP ₹70,951
Save 29%
3 Business Days
1
–
Download Product LeafletNot available
Download Insize CatalogueNot available
Download Insize CatalogueNot available
Highlights
- Data Output
- Switch between DC or AC measurement mode
- Display N/S polarity of DC magnetic field
- Zero function: eliminate the influence of zero drift before measurement
- Maximum value hold: record the maximum value of the changing magnetic field
- Auto ranging
- Relative measurement mode
- Set upper and lower alarm limit
- Built-in USB interface for data transmission
- Display with backlight
- Auto power off
What's Included in this Package:
- 1 x Tesla meter
- 1 x Radial Probe (0502-PR)
- 3 x AA Batteries
Please Note that Product may differ eg. colour, size from the product Image displayed on website. Kindly check the specifications provided to make better purchase decision. M.R.P Prices and specifications are subject to change without notice.
Specifications
| Range | 2500mT |
|---|---|
| Resolution | 0.001mT (<30mT) / 0.01mT (30 - 300mT) / 0.1mT (300 - 2500mT) |
| Unit | mT, G, Oe, kA/m (1mT=10G=10Oe=0.8kA/m) |
| Accuracy | ±2.0% (DC) / ±5.0% (AC) |
| Frequency Range | 40 - 500Hz (DC) |
| Temperature Coefficient | ±0.1%/K |
| Zero Drift | ±0.1mT/h |
| Interface | USB |
| Operation Environment | 0 - 45°C (Temperature) / 20% - 80%RH (Humidity), Non-Condensing |
| Storage Environment | -20°C ~ 70°C (Temperature) / <85%RH (Humidity), Non-Condensing |
| Power Supply | 3 x 1.5V AA Batteries or USB |
| Dimension (LxWxH) | 165 x 90 x 40 mm |
