Insize 50X - 600X Basic Type Metallurgical Microscope (Bright Field Objectives), 5102-M600
Roll over the image to zoom in
Key Features
- Product Type: Zoom Stereo Microscope
- Weight: 11 kg
- Magnification: 50X - 600X
- Objective: 5X - 60X (Bright Field Objectives)
ToolBuy Benefits
- Secure Payments
- Order Tracking (opens in a new tab)
₹2,42,456 (Incl. of all taxes)
₹2,05,471 + ₹36,985 GST (18%)
Out of Stock
3 Business Days
1
–
Download Product LeafletNot available
Download Insize CatalogueNot available
Download Insize CatalogueNot available
Highlights
- Infinite optical system, observation in reflected or transmitted illumination, polarizing observation
- Kohler illumination system provides uniform illumination field
- Objectives 40X, 60X are spring type
Technical Data:
| Objective(infinite Plan achromatic) (Bright Field Objectives) | Working Distance | Numerical Aperture |
| 5X | 26.1 mm | 0.12 |
| 10X | 20.2 mm | 0.25 |
| 40X | 3.98 mm | 0.60 |
| 60X | 3.18 mm | 0.70 |
Package Content:
- 1x Metallurgical Microscope
- 1x Anti-dust Cover
- 1 Pcs of each Filter (Blue / Frosted Glass)
Please Note that Product may differ eg. colour, size from the product Image displayed on website. Kindly check the specifications provided to make better purchase decision.
Specifications
| Magnification | 50X - 600X |
|---|---|
| Objective | 5X - 60X (Bright Field Objectives) |
| Eyepiece (Wide Field) | 10X (View Field: Ø22 mm) |
| Stage Layer | Double |
| Stage Size | 210 x 140 mm |
| Stage Travel | 75 x 50 mm |
| Pupil Distance | 53 - 75 mm |
| Diopter Adjustment | ±5 Diopter (One Eyepiece) |
| Power Supply | 220V, 50/60Hz |
| Illumination | 6V/30W (Transmitted & Reflected) |
| Dimensions (L x W x H) | 456 x 260 x 498 mm |
