Mitutoyo 0 - 25 mm Spherical Anvil Tube Micrometer (Type E), 115-115
Roll over image to zoom zoom_in
- Weight: 180 Grams
- Product Type: Tube Micrometer
- Range (mm): 0 - 25 mm
- Graduation (mm): 0.01 mm
- Anvil / Spindle: Type E (Spherical Anvil SR=4 mm / Flat Spindle)
- receiptGST Invoice
- headphonesCustomer Service
- lockSecure Payments
- policyReturns & Warranty
- home_pinOrder Tracking
- paymentsBuy in Installments
₹4279.86 (Incl. of all taxes)
₹3627+ ₹652.86 GST (18%)
MRP ₹4650
SAVE 22%
3 Business Days
1 Pcs
90173010
picture_as_pdfDownload Product Leafletkeyboard_double_arrow_right
picture_as_pdfBrand Authorization Certificatekeyboard_double_arrow_right
picture_as_pdfDownload Bosch Cataloguekeyboard_double_arrow_right
picture_as_pdfBrand Authorization Certificatekeyboard_double_arrow_right
picture_as_pdfDownload Bosch Cataloguekeyboard_double_arrow_right
Highlights
This Tube Micrometer allows you to measure curved surfaces such as the wall thickness of tubes, bearings and rings.
Please Note that Product may differ eg. colour, size from the product Image displayed on website. Kindly check the specifications provided to make better purchase decision. M.R.P Prices and specifications are subject to change without notice.
Features:
- Carbide-tipped spindle and anvil ensure durability and wear resistance
- Ratchet-stop mechanism provides uniform measuring pressure for accuracy
- Specially designed for checking wall thickness across various tubing types
Package Content:
- Tube Micrometer
- Spanner
Please Note that Product may differ eg. colour, size from the product Image displayed on website. Kindly check the specifications provided to make better purchase decision. M.R.P Prices and specifications are subject to change without notice.
Specifications
| SKU | ME.MI.TU.00021 |
|---|---|
| Product Type | Tube Micrometer |
| Model No | 115-115 |
| Range (mm) | 0 - 25 mm |
| Graduation (mm) | 0.01 mm |
| Max. Permissible Error (JPME) | ±3µm |
| Diameter (mm) | Ø10 mm |
| Measuring Force | 5 - 10 |
| Flatness | 0.6µm |
| Anvil / Spindle | Type E (Spherical Anvil SR=4 mm / Flat Spindle) |
| Measuring Spindle | With Spindle Lock, ø6.35 mm, Spindle Pitch 0.5 mm |
| Scale Finishing | Thimble & Sleeve Satin Chrome Finish, ø18 mm |
