Cabs Electra 4-1/2 Digits / 96 x 96 mm Panel Flush Mounting AC Voltmeter (Single Phase), CE-0102V
Roll over image to zoom zoom_in
- Product Type: Digital Panel Meters
- Type of Product: Voltmeter
- Size: 96 x 96 mm sq
- Display: 4-1/2 Digits LED Display (14/12 mm)
- receiptGST Invoice
- headphonesCustomer Service
- lockSecure Payments
- policyReturns & Warranty
- home_pinOrder Tracking
- paymentsBuy in Installments
₹2914.60 (Incl. of all taxes)
₹2470+ ₹444.6 GST (18%)
MRP ₹3632
SAVE 32%
5 Business Days
1 Pcs
90303100
picture_as_pdfDownload Product Leafletkeyboard_double_arrow_right
picture_as_pdfBrand Authorization Certificatekeyboard_double_arrow_right
picture_as_pdfDownload Bosch Cataloguekeyboard_double_arrow_right
picture_as_pdfBrand Authorization Certificatekeyboard_double_arrow_right
picture_as_pdfDownload Bosch Cataloguekeyboard_double_arrow_right
Highlights
4-1/2 Digits Red LED Display, panel flush mounting AC Voltmeter, for measuring AC Voltage, Size – 96 x 96 mm, range 0 – 20mV / 200mV / 2V / 200V / 1000V (Any One Range)
Features:
- Voltmeters for measuring AC voltages.
- Range: Any Single Range up to 1000V for direct input to the meter ‘or’ KV rating through a PT input can be made available.
- Auxiliary Power Supply: 230V AC 50Hz / 110V DC 50Hz / DC Auxiliary inputs also available
- At the time of placing the order, please inform the Voltage range, PTR value (if the input is through a PT), auxiliary power supply, size, 4-1/2 digits display needs to be mentioned.
Please Note that Product may differ eg. colour, size from the product Image displayed on website. Kindly check the specifications provided to make better purchase decision. M.R.P Prices and specifications are subject to change without notice.
Specifications
| SKU | EL.IN.DI.00031 |
|---|---|
| Product Type | Digital Panel Meters |
| Model No | CE0102V |
| Type of Product | Voltmeter |
| Size | 96 x 96 mm sq |
| Display | 4-1/2 Digits LED Display (14/12 mm) |
| Accuracy | ACV 0.5% Rdg +/- 3 Dgts |
| Sampling Time | Abt. 0.4 Sec typically |
| Frequency Range | 45-400 Hz for A.C. range |
| Over Range Indication | ''1'' |
| Power Consumption | AC 5VA |
| Operating Temperature Range | 0°C to 50°C |
| Storage Temperature Range | 10 ~ 70ºC |
| Max Relative Humidity | 95% |
| Dielectric Strength | AC 2KV/1Min |
| Aux Supply Source | 230V/110V/50/60Hz ‘OR’ 24 – 110V DC (Any One) |
