• Suitable for electric power, oil and petrochemical, heating ventilation and air conditioning, electronic information, etc.
• 4 image modes: IR, VL, MIF and PIP
• Software is included: support file management, thermal image analysis, video analysis, report editing, etc.
• Mobile APP is included: support real-time data and video transmission

Technical Data:

Measurement & Analysis	measurement accuracy	±2°C or ±2%, whichever is greater
	analyzed target	12 in total (spot/line/area)
	temperature alarm	full screen temperature alarm with image, voice & flash
	temperature measuring parameter	emissivity, reflected temperature, target distance, humidity, atmospheric temperature, optical transmittance, dew point
	others	isothermals, smart stroke, intelli entl calculate the area
Image Display	display screen	4.3 inch touchscreen LCD, 800x480 pixel
	digital camera	8MP
	image mode	IR, VIS, MIF, PIP
	image adjustment	level span mode: automatic, semi-automatic, manual
	color palettes	15: white hot, iron red, arctic, rainbow 2, hot iron, rainbow 1, fulgurite, medical, tint, black hot, blue hot, sepia, green hot, ice and fire, amber; customized
Imaging & Optics	detector type	unrefrigerated vanadium oxide, 7.5µm-14µm
	infrared resolution	480x360@12µm
	super resolution	upgrade to 960x720 Pixel
	thermal sensitivity/NETD	45mK
	infrared frame rate	30Hz/9Hz
	focal length	17.7mm
	field of view	25°x19°
	spatial resolution/lFOV	0.91 mrad
	minimum object distance	0.15 m
	distance to spot size/D:S	1099:1
	focusing mode	manual, automatic, touch autofocus, continuous autofocus
	digital zoom	1.1x - 16x
Function	laser	indication/ranging: 0.1m - 40m
	recording function	photo (image stitching) and video (infrared and visible light)
	cloud service	available
Storage & Transmission	storage	built-in 64GB and external SD card (64GB and up to 256GB)
	image storage	JPG (with temperature information)
	video storage	MP4 (without temperature information) can be used to record audio synchronously; IRGD (with temperature information), up to 30Hz for temperature analysis
	external interface	TYPE-C, SD card slot, 1/4" tripod mounting
	WIFI	can be connected to the mobile terminal for image and real-time video transmission
	bluetooth	Bluetooth 5.0, supports image transmission (only for Android)
Power Supply	battery type	lithium-ion rechargeable battery, operating time >24 hours
	charging mode	TYPE-C charging; PC/portable charger; capable of charging while using; desktop charger
	charging time	90% of full charge in 2.5 hours

Standard Delivery:

• 1x Infrared Thermal Imaging Camera
• 1x Standard Infrared Lens
• 1x 64GB SD Card
• 2x Li-ion Batteries
• 1x Desktop Charger
• 1x Power Adapter
• 1x Software
