• Magnetic induction probe (FM) measures the thickness of non-magnetic coating and non-metallic coating on magnetic metal substrate. Substrate: steel, iron, alloy, hard magnetic steel, etc. Coating: zinc, aluminum, chrome, copper, rubber, paint, etc.
• Eddy current probe (NM) measures the thickness of non-conductive coating on non-magnetic metal substrate. Substrate: copper, aluminum, zinc, tin, etc. Coating: rubber, paint, plastic, anodized film, etc.
• Real-time temperature compensation guarantees high accuracy, thin plating and oxide layer less than 20um can be measured accurately
• Reduces the effects of electromagnetic interference and hand-held operation
• The probe can be re-matched after abrasion
• Tolerance measurement with adjustable alarm threshold
• USB and bluetooth interface for data transmission and online measurement in real-time
• Coupling status indication
• Support cable printer
• Measuring Mode: Single point measurement, Scan mode, Differential mode, Average mode
• Calibration Mode: Zero calibration, One-point calibration, Two-point calibration, Multi-point calibration

Accuracy:

Zero Calibration	±(1µm+2%L)
Multi-point Calibration	±(1µm+1%L)

Standard Delivery:

Main unit	1 pc
Magnetic induction probe (FM)	1 pc
Zero calibration block for FM probe	1 pc
Calibration Foils (12µm / 50µm / 100µm / 250µm / 500µm / 1000µm)	6 pc
AAA batteries	3 pcs
Software and USB cable	1 pc
