• Suitable for electric power, electrical industry, mechanical industry, etc.
• Adopt a 256x192 infrared detector, together with a 1920x1080 visible light sensor
• Support real-time temperature measurement analysis, alarm setting, historical information query and export reports
• Support various installation methods such as magnetic mounting, wall mounting, vertical mounting, hanging mounting and tripod mounting
• Web-side control, no need for other apps or software

Technical Data:

Infrared Image	detector type	unrefrigerated vanadium oxide, 7.5µm - 14µm
	infrared resolution	256x192 Pixel @12µm
	thermal sensitivity/NETD	45mK@30°C
	lens	3.2 mm, 56°x42°
	focusing mode	focus-free
	color palettes	26: white hot, black hot, rainbow and so on
	featured function	detail enhancement, 2D/3D noise reduction, image flip, dual light fusion
Temperaturement Measurement	measurement range	low: -20°C ~ 150°C, high: 100°C - 550°C
	measurement accuracy	±2°C or ±2%, whichever is greater
	measurement target	up to 21 targets (spot, line, rectangle, polygon and circle) can be simultaneously measured
	measurement function	cold/hot spot tracking, full-screen point temperature measuring, query and export of information
Visible Light	sensor type	1/2.7" CMOS
	max. resolution	1920 x 1080 Pixel
	min. illuminance	color: 0.005 lux
	lens	2.8 mm, 65° x 49°
	fill light	white light
	featured function	visible light gain control, 2D/3D noise reduction, backlight compensation, wide dynamic, strong-light photoinhibition, image flip, exposure compensation
Protocol & Storage	network protocol	IPv4/lPv6, HTTP, SMTP, RTSP, TCP, DHCP, ONVIF (automatic search device, RTSP video stream and device control), GB/T28181, MQTT
	local storage	4G EMMC
System Function	language	Chinese/English
	user management	max. 20 users with three levels of user accounts (root, admin and user)
	fault detection	network interrupt detection, IP conflict detection, illegal access, storage exception
	intelligent function	sound and light alarm
Interface	power interface	DC12V±25%
	network interface	100M/1000M Ethernet port, POE (802.3at)
	alarm interface	1 input and 1 output
	other interface	RS485

Package Content:

• 1x Main Unit
• 1x Adapter Cable
• 1x Back Panel
