• The 256x192 infrared detector produces crisp image
• The IR, VIS, PIP and MIF reveal temperature details
• -20°C to 550°C temperature range with auto-switching capability
• Software is included

Technical Data:

Measurement and analysis	Measurement range	support auto-switching: -20°C~150°C, 100°C-650°C
	Measurement accuracy	±2°C or ±2%, whichever is greater
	Analyzed target	spotx2 (Include Center Spot), areax3
	Tracking/alarm	Full screen maximum, minimum and average temperature tracking; The maxium, minimum and average temperature tracking of analyzed target; Full screen temperature threshold alarm (image, voice and flash)
	Temperature measuring parameter	Emissivity, Reflected Temperature, Target Distance
	Other	Intelligently calculate the area
Image Display	Display Screen	3.5" LCD
	Digital Camera	5 MP
	Image Code	IR, VIS, MIF, PIP
	Image Adjustment	level span mode: automatic, semi-automatic, manual
	Color Palettes	white hot, iron red, arctic, hot iron, rainbow, black hot
Function	Recording Function	Photo
	Cloud Service	Available
	Other	Customized physical button x 2
Storage & Transmission	Storage	local storage (16GB)
	Image Storage	JPG with temperature information
	Video Storage	MP4 (without temperature information), Can be used to record audio synchronously; Irgd (with temperature information), up to 30 Hz for temperature analysis
	External Interface	Type-C
	WiFi	can be connected to the mobile terminal for image transmission
Power System	Battery Type	Lithium-ion rechargeable battery, working time>4 hours
	Charging Mode	Type-C charging; PC/portable charger; capable of charging while using
	Charging Time	90% of full charge in 2.5 hours
Environmental Parameter	Operating Temperature	-10°C ~ 50°C
	Storage Temperature	-40°C ~ 70°D
	Protection	IP54, 1-meter drop test
	Certification	CE, FCC, ROHS
Physical Parameter	Hardware	illuminator, Laser (Indication, Ranging)

Standard Delivery:

• 1x Main Unit
• 1x Power Adapter
• 1x Software
