• Non-Rotating Spindle
• Absolute Encoder, The Original Data Remains After Power off
• IP65 Waterproof
• Data Output
• One Turn of Sleeve Makes 5mm Spindle Feed Press The Fork The Spindle Retracts 3mm
• Measurement Accuracy Is Not Affected By the Use Of Sleeve
• Absolute encoder, the original data remains after power off
• Adjustable resolution: 0.0002mm/0.00001"
• 0.001mm/0.00005"
• 0.01mm/0.0005"
• One turn of the sleeve makes 5mm spindle feed
• Measurement accuracy is not affected by the use of sleeve
• Press the fork, the spindle retracts 3mm
• Linear ball bearings for ten million times use
• Carbide spindle and anvil
• Measuring force 7-10N. Customizable measuring force range 2-12N. Attention: small measuring force will reduce the dustproof and waterproof level
• Button function: data output, tolerance, data preset, data hold, measuring direction change, max./min./TIR, power-off time, on/off, zero, mm/inch, adjust resolution
• Supplied with gage blocks for zero setting
• (except 0-25mm/0-1")
• Power: rechargeable battery, for 24 hours continuous working.

With Data Interface:

• Optional accessory:
• wireless transmitter, code 7315-60, wireless receiver, code 7315-2, 7315-3
• data output cable (keyboard format), code 7302-60 data output cable (serial port format), code 730-G60
• (cable length 3m, optional cable length maximum 15m; RS232 protocol, optional RS485 protocol, optional RS485 protocol)

Attention:

• Rechargeable Battery, For 24 Hours Continous Working.
