Winches are the perfect solution for raising or lowering of personnel or material into confined spaces, Karam provides equipment that allows easy overhead access into and retrieval of personnel and material from such confined space areas.

Karam Tripod is one such product that can be used for easy access by a worker into confined spaces such as Man-holes, Tanks, etc. It provides a means of controlled ascent and descent, as well as protection from falls, should the depth of the space require it.

Features:

• Winch Line : Synthetic Rope of dia 6.5mm
• Length of cable : upto 35mtrs
• Connector : Steel Swivel Snap Hook Ref. PN 162
• Maximum lifting load capacity as per EN 1496 : 135 kgs
• Maximum lifting load capacity as per machinery directive 2006/42/EC : 250 kgs
• Compatibility : Can be mounted on Tripods, Megapod, Hexapod & K-Pod with the help of their universal mounting brackets respectively
• Inbuilt Shock Absorption : Yes
• Independent Reel Mode : Yes
• Secondary Brake mechanism : Yes
• Conforms to : EN 1496:2017 (Class B) & ANSI Z 359.4-2013
