• 4 - 20mA (1kΩ Load, 24V Loop Output).
• 0 - 20mA and 0 - 24mA output ranges.
• 0.025% Basic Accuracy.
• Auto Ramp and Step functions.
• 0 - 100% output with percentage step option.
• 0 - 24V DC voltage source.
• Open the loop and overload the buzzer alarm.
• Low battery indication.
• Simple Operation Interface
• Warning beeper when output is open

Technical Data:

DC Current (1kΩ Max Load, 24V Loop Supply)

Range	Resolution	Accuracy
0 - 4 mA	1 µA	±(0.025% rdg + 10µA
4 - 20 mA		±(0.025% rdg + 5µA)
0 - 24 mA



DC Voltage

Range	Resolution	Accuracy
0 ~ 20 V	1 mV	±(0.05% rdg + 10mV)
4 ~ 20 V		±(0.05% rdg + 5mV)
20 ~ 24 V

Package Content:

• Loop Calibrator
• DC Adapter
• Test Leads
• Carry Case
• Battery
• Instruction Manual
