On-line monitoring of loop grounding resistance and metal loop coupling resistance, and grounding condition monitoring.

Features:

• Split Type, no need to disconnect the grounding down conductor, easy to install, non-contact measurement technology, safe and reliable.
• The grounding down conductor directly passes through the detector perforation, which does not affect the lighting protection grounding effect and the normal operation of the facility.
• The detector with an audible and visual alarm. KM 1680C with LCD that can be installed and used independently.You can observe the grounding resistance value at any time & set the alarm value.
• The detector with an audible and visual alarm. KM 1780KC with LCD that can be installed and used independently. You can observe the grounding resistance value at any time & set the alarm value
• With Rs485 interface, network system can be set up to realize remote real-time monitoring.
• Explosion-proof products can be used in the corresponding flammable and explosive environment, explosion-proof mark: Ex iallBT3G
• Data Display: 4 digit LCD direct indication or doing secondly development Software to display
• Overflow Indication: When show value is beyond 200°, system software and LCD shows “OLΩ” sign
• Alarm indication: Detector sound and light alarm, system software alarm indication

Package Content:

• Explosion-proof Split Type Ground Resistance On-Line Detector
• Detector
• Hardware fixing screws
• Flat steel compression screw
• Cable
• User manual.
