• 250MSa/s sample rate, 16 bit vertical resolution and 16Mpts waveform length
• Rise/fall time of Square: ≤4.2ns
• Removable PA (option)
• Optional IOT interface
• High precision frequency counter
• 7" Touch screen display

Technical Data:

Frequency
Sine/Square	1μHz∼35MHz
Pulse	1μHz-25MHz
Ramp	1μHz-3MHz
PRBS	1kbps∼60Mbps
Noise (-3dB)	100MHz bandwidth
Other	1μHz ∼ 20MHz
Resolution	1μHz or 12 digits
Accuracy	±(20ppm+4pHz)
Waveform
Type	165 kinds include: Sine, Square, Ramp, Pulse, Noise, DC, PRBS, user-defined Arbitrary waveform, user-defined harmonic, etc
Arbitrary	Sample Rate: 1µSa/s ~ 125MSa/s Length: 2 - 16Mpts Resolution: 16 Bits
Square	Rise/Fall Time: <4.2ns Duty Cycle: 0.0001% - 99.9999%
Pulse	Rise/Fall Time: >8ns Width: 13ns ~ (Period - 13ns)
DC Offset (High-Z)
Rang	±10Vpk(ac+dc)
Resolution	1mVdc
Pulse (Rise/Fall Time)	≥8ns
Accuracy	±(|setting value|x1%+amplitude valuex0.5%+2mV)
Counter
Frequency Range	1mHz to 350MHz (DC Couple) 10Hz to 350MHz (AC Couple)
Resolution	8 Digits/s
Period & Pulse Width Measurement	100ns to 20s
Duty Cycle Measurement	0.1% to 99.9%
Amplitude (High-Z)
Range	2mVpp ~ 20Vpp, frequency<10MHz 2mVpp ~ 10Vpp, frequency>10MHz
Resolution	1mVpp or 4 digits
Accuracy	±(of settings value x 1%+1mV), Sine 1kHz, >10mVpp, offset 0V
Modulation
FM,AM,PM,PWM,Sum	Carrier Waveform: Sine, Square, Ramp (only pulse for PWM), etc. Modulatin Waveform: Sine, Square, Ramp etc. Modulating Frequency: 1mHz to 100kHz
FSK, 4FSK, NFSK, PSK, 4PSK, NPSK, ASK, OSK	Carrier Waveform: Sine, Square, Ramp etc. Hope Frequency: 1µHz  -upper Limits Hope Rate: 1mHz to 1MHz
Power	AC 100 - 240V 50/60Hz±10% AC 100 - 120V 400Hz±10%

Packages Content:

• 1x Waveform Generator
• 1x Power Cord
• 1x BNC Cable
• 1x CD (Software + Manual)
