• One Navigator Key Operation
• 16,384 pixels thermal image after interpolation
• True D/S 30:1 with precise laser indication.
• Bright flashlight with 5 white LEDs
• Simple, Smart, Precise and Versatility.
• 160x128 pixel 1.77 inches TFT-LCD Display
• Alkaline AA size x 3 Batteries
• Key chain with wrist strap for carrying convenience
• SD Card of 2GB is available.
• Compact UV refrigerant leak detector with 5UV/Blue LEDs
• Ergonomically designed pistol grip housing with excellent industrial Design

Technical Data:

• Temperature Range: -30°C to 650°C (-22°F to 1202°F)
• Accuracy: ±1.5°C or ±1.5% of reading ±2.0°C at -10°C to 0°C ±3.0°C at -30°C to -10°C
• Response Time(95%): < 300 ms (95% of reading)
• Optical Resolution: 30:1 (Calculated at 95% Energy)
• Display Resolution: 0.1°C (0.2°F)
• Repeatability of Readings: ±0.5% of reading or < ±0.5°C (1°F), whichever is greater

SD Card & PC Connection:

• SD Card of 2GB is available.
• A 2GB SD Card is inserted left side of the Thermal Image Camera.
• A USB slot is also given to directly connect to the PC and view the image.
• Connect any USB Cable to the PC and the Imager TG-301 should be in OFF mode then connect to the PC. If in ON mode the USB cannot be connected to show files.
• In the Thermal Image Camera menu option, the saved images can be seen directly on the screen of the image camera.
• When connected to the PC with a USB cable do not ON the imager. It will not start.

Thermal Imaging:

• Imaging Detector: IR Array
• Image Resolution: 16,384 Pixels (128 x 128 Pixels)
• Field of View (H X W): 30°C
• Upper Sense Range: 650°C
• Thermo Imaging Sensitivity: 150 mK
• Color Palettes: 3 (Grey Scale, Hot Iron, Rainbow)
• Saved Image Format: Bitmap (BMP) Image with Temperature and Emissivity

Safety:

• Vibration and Shock: IEC 68-2-6 2.5 g, 10 to 200 Hz, IEC 68-2-27, 50 g, 11 ms
• EMC: EN 61326-1:2006, EN 61326-2:2006
• Compliance and Laser Safety: EN/IEC 61010-1: 2001, EN 60825-1 Class II

Package Content:

• Handheld Thermal Camera
• User Manual
• Batteries
• SD Card
• USB Cable
• Carrying Case
