• Microprocessor-controlled Menu Driven
• Test Insulation Resistance up to 30T Ω (30000G Ω)
• Test Insulation Voltage up to 15kV
• Short circuit current up to 5mA
• AC / DC Voltage: 600V
• PI & DAR indication.
• Auto-ranging on all insulation ranges
• 2 Lines X 16 Characters large LCD Backlight display
• Bargraph indicates test Voltage, rise and decay can be observed
• Visual & audible warning if an external voltage is present. ( 30Vac or 30Vdc)
• Auto-hold function to freeze the reading
• Overload Protection
• Adjustment for testing time (duration) :1 ~ 30 minutes
• Auto-off
• Calendar
• Optical USB to RS-232 data transmission
• 200 measurement results can be saved in the memory & recalled on the display
• Measuring 30 Insulation Test Voltage Ranges: 500V, 1kV, 1.5kV, 2kV, 2.5kV, 3kV, 3.5kV, 4kV, 4.5kV, 5kV, 5.5kV, 6kV, 6.5kV, 7kV, 7.5kV, 8kV, 8.5kV, 9kV, 9.5kV, 10kV, 10.5kV, 11kV, 11.5kV, 12kV, 12.5kV, 13kV, 13.5kV, 14kV, 14.5kV, 15kV
• Resolution: 1GΩ: 0.001GΩ / 10GΩ: 0.01GΩ / 100GΩ: 0.1GΩ / 1TΩ: 1GΩ / 10TΩ: 10GΩ / 30TΩ: 100GΩ
• Voltmeter - ACV: 30 ~ 600V (50/60Hz) / DCV: 30~600V / Accuracy: ±(2.0%rdg+3dgt) / Resolution : 1V

Technical Data:

Accuracy

1kV: 0~200GΩ 5kV: 0~1TΩ 10kV: 0~2TΩ 15kV: 0~3TΩ	±(5%rdg+5dgt)
1kV: 200GΩ ~ 2TΩ 5kV: 1TΩ ~ 10TΩ 10kV: 2TΩ ~ 20TΩ 15kV: 3TΩ ~ 30TΩ	±20%



Safety:

• EN61010-1 CAT IV 600V EN61010-2-030; EN61326-1
