AmpTip™ low-current range calibrated at Jaw-tip for slim conditions for accurate readings. VFD-V & Hz for fundamental V/Hz of most Variable-Frequency-Drives

Features & Benefits:

• MAX/MIN/AVG Recording mode (Auto-ranging)
• Display Hold & Non-Contact EF-Detection (NCV)
• Back-lighted easy-to-read LCD display
• Fast 80ms Peak-RMS mode to capture in-rush currents
• Auto-ranging Relative mode with DCZero mode & 5ms Crest (Instantaneous Peak-Hold) mode

Safety:

• Double insulation per UL/IEC/EN61010-1 Ed. 3, IEC/EN61010-2-033 Ed.1, CAN/CSA C22.2 No.61010-1 Ed. 3, IEC/EN61010-2-032 Ed. 3 & IEC/EN61010-031 Ed. 1.1
• Measurement Category: CAT III 600V AND CAT IV 300V AC & DC
• E.M.C.: Meets EN61326-1 : 2006 (EN55022, EN61000-3-2, EN61000-3-3, EN61000-4-2, EN61000-4-3, EN61000-4-4, EN61000-4-5, EN61000-4-6, EN61000-4-8, EN61000-4-11) : DCA and DC+ACA Functions, in an RF field of 1V/m: Total Accuracy = Specified Accuracy + 20 digits at around 405MHz Ohm Functions, in an RF field of 1V/m: Total Accuracy = Specified Accuracy + 25 digits Other Functions, in an RF field of 3V/m: Total Accuracy = Specified Accuracy + 20 digits
• Overload Protection: Current & Hz functions via jaws : 600ADC/AC rms at <400Hz; Voltage : 660VDC rms; Other functions via terminals : 600VDC/ VAC rms
• Pollution Degree: 2 / Rugged Fire retarded casing
• Transient Protection: 6.0kV (1.2/50µs surge)
• LVD EN61010-2-032/EN61010-2-033 to CAT III 1000V & CAT IV 600V

Package Content:

• Test leads set
• Users Manual
• Carrying case
