AmpTip™ low-current range calibrated at Jaw-tip for slim conditions for accurate readings. VFD-V & Hz for fundamental V/Hz of most Variable-Frequency-Drives

Features & Benefits:

• MAX/MIN/AVG Recording mode (Auto-ranging)
• Display Hold & Non-Contact EF-Detection (NCV)
• Probe-Contact EF-Detection
• Relative Humidity - Maximum relative humidity 80% for temperatures up to 31°C decreasing linearly to 50% relative humidity at 40°C
• Temperature Coefficient - Nominal 0.15 x (specified accuracy) /° C @ (0 ° C - 18 ° C or 28 ° C - 40 ° C), or otherwise specified
• Low Battery - Below approx. 2.85V for Capacitance & Hz / Below approx. 2.5V for other functions

Safety:

• Double insulation per UL/IEC/EN61010-1 Ed. 3, IEC/EN61010-2-033 Ed.1, CAN/CSA C22.2 No. 61010-1 Ed. 3, IEC/EN61010-2-032 Ed.3 & IEC/EN61010-031 Ed. 1.1
• Measurement Category - CAT III 600V AND CAT IV 300V AC & DC
• E.M.C. - Meets EN61326-1: 2006 (EN55022, EN61000-3-2, EN61000-3-3, EN61000-4-2, EN61000-4-3, EN61000-4-4, EN61000-4-5, EN61000-4-6, EN61000-4-8, EN61000-4-11): DCA and DC+ACA Functions, in an RF field of 1V/m: Total Accuracy = Specified Accuracy + 20 digits at around 405MHz DCmA and Ohm Functions, in an RF field of 1V/m: Total Accuracy = Specified Accuracy + 25 digits / Other Functions, in an RF field of 3V/m: Total Accuracy = Specified Accuracy + 20 digits
• Overload Protection: Current & Hz functions via jaws : 600ADC/AAC rms at <400Hz / Voltage & 3-Phase Rotation functions via terminals : 660VDC/ 920VAC rms; Other functions via terminals : 600VDC/ VAC rms
• Pollution Degree: 2 / Rugged Fire retarded casing
• Transient Protection: 6.0kV (1.2/50ms surge)
• Rugged Fire retarded casing.
• LVD EN61010-1/61010-2-032/EN61010-2-033 to CAT III 600V & CAT IV 300V

Package Content:

• Test leads set
• Users Manual
• Battery & Carrying Case

Please Note that Product may differ eg. colour, size from the product Image displayed on website. Kindly check the specifications provided to make better purchase decision. M.R.P Prices and specifications are subject to change without notice.
