• 4 pole Earth Resistance Measurement up to 209.9k ohms with resolution 0.001 ohm.
• Soil Resistivity measurement 0 - 209.9k Ωm.
• Advanced filtering method based on FFT (Fast Fourier Transform) reduces noise interference.
• Rich test results displayed include the resistance of earth spikes, frequency of test current, detected voltage & frequency of interference, residual resistance Rk, etc.
• Auto / Manual frequencies are optional (94/105/111/128Hz).
• Compensation for residual resistance Rk.
• Data memory 1000 sets.
• Confirms to CATIV 150V, CAT III 300V.
• Earth Resistance: 2Ω: 0.05 ~ 2.09Ω / 20Ω: 0.05 ~20.9Ω / 200Ω: 0.3 ~ 209Ω / 2000Ω: 3 ~2.09kΩ / 20kΩ: 0.03k ~ 20.9kΩ / 200kΩ: N/A
• Soil Resistivity Voltage: 2Ω: 0.3 ~ 393.7Ωm / 20Ω: 3 ~ 3937Ωm / 200Ω: 0.03 ~ 39.37kΩm / 2000Ω: 0.3k ~ 393.7kΩm / 20kΩ: 3k ~ 1999kΩm / 200kΩ

Safety:

• IEC61010-1 CAT III 300V, CAT IV 150V. Pollution Degree 2, IEC61010-031, IEC61557-1,5, IEC61326-1(EMC).

Package Content:

• 4 terminal earth wires & spikes
• Instruction Manual
• Battery
• Carrying Case
