• 300AAC, 1000VDC, 750VAC
• True RMS
• Micro-Controller design with high accuracy
• Sharp and contrasting display
• Freauency, Duty Cycle, RESISTANCE, diode functions
• Line test
• Capacitance measurement
• Double insulated
• Temperature measurement
• Data Hold
• Backlit Display
• Over2 load protection on all ranges
• Automatic polarity indication recessed safety designed input jacks


What's Included In This Package:

• 1x Test Leads
• 1x Instruction Manual
• 1x K-Type Thermocouple Leads
• 1x Carrying Case



Specifications:

DC Voltage (Auto Ranging):

Range	Resolution	Accuracy
600mV	0.1mV	+(0.8% of reading + 3 dgts)
6V	1mV	+(0.8% of reading + 3 dgts)
60V	10mV
600V	100mV
1000V	1V	+(1.0% of reading + 5 dgts)

Maximum Input Voltage: 1000VDC

AC Current (Auto Ranging):

Range	Resolution	Accuracy
6A	10mA	±2.5% of reading ± 10 digits
60A	100mA
300A	1A

Maximum Input Current: 300AAC
Frequency Response: 40-1000Hz True Rms

Resistance (Auto Ranging):

Range	Resolution	Accuracy
600Ω	0.1Ω	+1.0% of reading ± 5 digits
6KΩ	1Ω
60ΚΩ	10Ω
600ΚΩ	100Ω
6MΩ	1KΩ
60ΜΩ	10ΚΩ

Open Circuit Voltage: 0.25V (Approx.)
Overload Protection : 250VDC/AC (rms)

Frequency (Auto Ranging):

Range	Resolution	Accuracy
1Hz	0.001Hz	±1.0% of reading ± 5 digits
10Hz	0.01Hz
100Hz	0.1Hz
1KHz	0.001KHZ
10KHz	0.01KHZ
100KHz	0.1KHZ
10MHz	10MHz 0.001MHz

Overload Protection: 250V DC/AC (rms)

AC Voltage (Auto Ranging):

Range	Resolution	Accuracy
600mV	0.1mV	±(1.2% of reading + 8 dgts)
6V	1mV	±(1.2% of reading + 6 dgts)
60V	10mV
600V	100mV
750V	1V	±(1.2% of reading + 8 dgts)

Maximum Input Voltage: 750VAC
Frequency Response: 40-1000Hz Trms
Input Impedance: 10MQ

Temperature:

Range	Range	Accuracy
-40-1370°C	1°C	-40°C-150°C	±1.0% + 4 digits
		150°C-1370°C	±2.0% +3 digits
-40-2000°F	1°F	-40°F-302°F	±5.0% + 4digits
		302°F-2000°F	±4digits2.5% + 4digits

Capacitance (Auto-Range):

Range	Resolution	Accuracy
10nF	0.01nF	±8.0% of reading ± 5 digits
100nF	0.1nF
1µF	0.001μF
10µF	0.01µF
100μF	0.1µF
20mF	0.001mF

Overload Protection: 250VDC/AC (rms)

Diode and Continuity:

Range	Introduction	Remark
	The approx. forward voltage drop will be displayed	Open Circuit Voltage: about 3.0V
Buzzer Symbol	The built-in buzzer will sound if the resistance is less than 300Ω	Open Circuit Voltage: about 3.0V

Forward DC Current of about 1ma
Reverse DC Voltage of about 3.0V
Over Load Protection : 250VDC/AC (rms)
