An instrument with high accuracy and precision. Highest standard of technology incorporated in designing to achieve accuracy and stability. The performance is as par with the high-level device available in the market. The instrument is capable of interface with eight types of thermocouples and PT-100 (385). Input is selectable through software, no need to change any component or add on card.

The offset and input filter are also selectable to match the sensor reading. In addition, PT-100 gives 0.1°C resolution and high accuracy to meet pharmaceutical requirements. The instrument is capable of measuring from -200°C to 1800°C depending on the sensor. Its design makes it suitable for maintenance, service, and calibration of field temperature equipment.

Features:

• Contact Type
• Display- 4 Digit Seven Segment 0.36” LED Display Red
• Thermocouple- B, E, J, K, N, R, S, T
• PT- 100(385)
• Power Supply- 2 x 1.5V AA Battery
• Battery- Life Approximately 100 Hrs. Uninterrupted
• Enclosure Size- 135 x 70 x 25 (All in mm)
• Ambient Temperature-  0 to +50 °C
• Storage Temperature- 0 to +70 °C
• Humidity- 0-90 % RH (Non Condensing)



RTD	Range In °C (@Resolution 0.1°C)	Accuracy
PT-100 (385)	150 to 600	0.1% (3-Wire) ±2 Digit
Thermocople	Range In °C (@Resolution 0.1°C)	Accuracy
Type B	300 to 800	All 0.25% ±1 Digit
Type E	-200 to 1000
Type J	-200 to 1200
Type K	-200 to 1350
Type N	-200 to 1300
Type R	-50 to 1750
Type S	-50 to 1750
Type T	-200 to 390
