Complementary

[Ie] Rated operational current	100 A at 240 V AC
[Ui] Rated insulation voltage	6 kV
[Uimp] Rated impulse withstand voltage	500 V
Poles description	2P
Rated breaking capacity	2.5 kA
Short-circuit withstand	20 A
[Us] Rated supply voltage	48 V DC 1P 100 V DC 2P
Utilisation category	AC-22
Total number of 18 mm modules	2
Product destination	Distribution board

Environment

Ambient air temperature for operation	-20…50 °C
Pollution degree	3
Standards	IEC 60669-1 IEC 60947-3

Packing Units

Unit Type of Package 1	PCE
Number of Units in Package 1	1
Package 1 Height	7.4 cm
Package 1 Width	3.55 cm
Package 1 Length	8.5 cm
Package 1 Weight	170 g
Unit Type of Package 2	S01
Number of Units in Package 2	48
Package 2 Height	15 cm
Package 2 Width	15 cm
Package 2 Length	40 cm
Package 2 Weight	8160.55 g
Unit Type of Package 3	PAL
Number of Units in Package 3	384
Package 3 Height	80 cm
Package 3 Width	60 cm
Package 3 Length	80 cm
Package 3 Weight	65280 g
