ZENcelo - the World's first range of full flat switches - It’s about an in-standing way of being ! It is for people who live a tasteful life who can appreciate the most sophisticated as well as the simplest. Clear of all unnecessary lines and protrusions, it harmoniously blends in with every contemporary décor. While style, innovation and simplicity is the hallmark of this range - safety and reliability continues to be of paramount importance - be it through arc encapsulated switches or child proof sockets - ZENcelo assures complete safety at every interface. ZENcelo range of switches & sockets are tested and validated to last for more than a decade ! All in all - if you are looking for an outstanding yet subtle design - which is also classy and stylish without shouting out for attention - ZENcelo is the range you want !


• World's first full - flat mechanical switch
• Patented Iso - motion technology which ensures switch stays in th esame position whether On or Off
• Robust & strong design - material made of corrosion resistant, heat resistant and impact resistant polycarbonate
• Designed to Last for more than a decade - Switches tested to 80,000+ time

Complementary

Device mounting	Flush Surface
Communication network category	Voice: 3
Rated current	1.5 A
Contacts material	Housing: PC Contact: phosphor bronze with gold plating IDC contact: phosphor bronze with nickel plating
Contact resistance	1 µOhm
Insulation resistance	>= 100 MOhm
Width	23.5 mm
Height	52.4 mm
Depth	15.2 mm

Environment

Dielectric strength	750 V for 60 s at 60 Hz
AWG gauge	AWG 26...AWG 22 (4 twisted pair cables)
Environmental characteristic	No UV resistant
Ambient air temperature for operation	-5…35 °C
Relative humidity	0…95 %
Standards	ASTMD4566-98 TIA/EIA-568-B.2-1 TIA/EIA-568-B.2

Packing Units

Unit Type of Package 1	PCE
Number of Units in Package 1	1
Package 1 Height	5.3 cm
Package 1 Width	1 cm
Package 1 Length	2.4 cm
Package 1 Weight	16 g

Please Note that Product may differ eg. colour, size from the product Image displayed on website. Kindly check the specifications provided to make better purchase decision. M.R.P Prices and specifications are subject to change without notice.
