• Drop forged from Chrome - Vanadium Steel.
• Scientifically heat-treated with hardness 40 - 45 HRC to give maximum strength and wear resistance.
• Head at each end are of different sizes and set at an angle of 15°
• Good accessibility in confined spaces due to slim and practical design



Normal Features

• Slightly rounded handles -sand blasted- fit snugly in the hand and give a comfortable grip
• Clearly marked - facilitates choice of right size
• Non-damaging grip on the nut due to close wrench opening tolerances
• I-section design of handle and heads combines strength with low weight
• Thoroughly corrosion protected with Nickel-Chrome finish
• Jaw cheek portion is mirror polished gives rich feel
• Available in Metric and Inches with various sizes
• Taparia Double Ended Open Jaw Spanner generally Conform To I.S. 2028 - 2004



Minimum Torque Value In Kg.M

Nominal Width A/F	Torque Value In kg.M
6	0.60
7	0.90
8	1.30
9	1.90
10	2.50
11	3.30
12	4.20
13	5.30
14	6.50
15	7.80
16	9.40
17	10.90
18	13.00
19	15.20
20	17.50
21	20.20
22	22.90
23	26.00
24	29.30
25	32.80
26	36.60
27	40.70
28	45.00
29	54.60
30	65.50

Please Note that Product may differ eg. colour, size from the product Image displayed on website. Kindly check the specifications provided to make better purchase decision.
