UNI-T -20 to 400°C / -4°F to 752°F Pocket-sized Thermal Imaging Camera, UTi120P
Roll over image to zoom zoom_in
- Weight: 125 Grams
- Product Type: Thermal Imaging Camera
- Temperature Measurement Range: -20°C to 400°C / -4°F to 752°F
- Display: 2.4 inch TFT Display Screen (320×240 Pixels)
- IR Resolution: 120×90 Pixals
- receiptGST Invoice
- headphonesCustomer Service
- lockSecure Payments
- policyReturns & Warranty
- home_pinOrder Tracking
- paymentsBuy in Installments
₹22567.5 (Incl. of all taxes)
₹19125+ ₹3442.5 GST (18%)
MRP ₹22500
SAVE 15%
7 Business Days
1 Set
90275090
picture_as_pdfDownload Product Leafletkeyboard_double_arrow_right
picture_as_pdfBrand Authorization Certificatekeyboard_double_arrow_right
picture_as_pdfDownload Bosch Cataloguekeyboard_double_arrow_right
picture_as_pdfBrand Authorization Certificatekeyboard_double_arrow_right
picture_as_pdfDownload Bosch Cataloguekeyboard_double_arrow_right
Highlights
UTi120P thermal camera is mini and portable in size, users can put it into pocket to go anywhere to identify and troubleshoot problems, it can automatically track the objective’s temperature from -20°C to 400°C, which can be widely used in many applications.
Please Note that Product may differ eg. colour, size from the product Image displayed on website. Kindly check the specifications provided to make better purchase decision. M.R.P Prices and specifications are subject to change without notice.
Features:
- Mini and portable
- Auto alarm for high/low temperature
- Auto tracking for hot spot/cold spot
- Image capture
- PC software analysis
- Rechargeable Li-ion battery
- 1/4” tripod mounting hole
Application:
- PCBA inspection: The thermal camera can quickly locate the components where temperature is abnormally higher.
- Power Distribution Cabinet Inspection: The thermal camera can quickly find the problems on switcher, contactor, transformer etc, which maybe caused by oxidation, corrosion, poor contact.
- Motor inspection: The thermal camera can detect the imbalance loading, overloading, wiring error and parts malfunction etc. Heat insulation protection is the key action for avoid fire risk, users can also use the thermal camera check the protection situation regularly to ensure the safety production.
Package Content:
- 1x Thermal Imaging Camera
- 1x 3.7V 1350mAh Fixed Li-ion battery
- Hand strap
- Micro SD card
- Micro USB cable
- English manual
- Download the operation guide card
- Gift box
Please Note that Product may differ eg. colour, size from the product Image displayed on website. Kindly check the specifications provided to make better purchase decision. M.R.P Prices and specifications are subject to change without notice.
Specifications
| SKU | ME.TE.TH.00079 |
|---|---|
| Product Type | Thermal Imaging Camera |
| Model No | UTi120P |
| Temperature Measurement Range | -20°C to 400°C / -4°F to 752°F |
| Display | 2.4 inch TFT Display Screen (320×240 Pixels) |
| IR Resolution | 120×90 Pixals |
| Field of view (FOV) | 50° × 38° |
| Thermal Sensitivity (NETD) | < 60mK |
| Spatial Resolution (IFOV) | 7.3 mrad |
| Frame Rate | < 25Hz |
| Spectral Range | 8 ~ 14µm |
| Focus | Focus Free |
| Accuracy | ±2°C or ±2% whichever is greater |
| Emissivity | 0.01 ~ 1.00 Adjustable (0.95 Default) |
| Power Supply | 1x 3.7V 1350mAh Fixed Li-ion Battery |
| Battery Operation Time | >3.5 Hours |
| USB | Micro USB |
| Drop Proof | 1 Meter |
| Storage | Up to 32GB Micro SD card |
| Image/Video Storage Format | BMP |
| Certificates | CE,RoHS |
| Dimensions (mm) | 76 × 76 × 24 mm |
