UNI-T 4 to 90° Digital Angle Meter with Laser, LM320E
Roll over image to zoom zoom_in
- Weight: 180 Grams
- Product Type: Digital Angle Meter
- Rotation Range: 4° - 90°
- Resolution: ±0.05°
- Laser Lines: 2 Lines
- Laser Accuracy: ±3mm / 5m
- receiptGST Invoice
- headphonesCustomer Service
- lockSecure Payments
- policyReturns & Warranty
- home_pinOrder Tracking
- paymentsBuy in Installments
₹2357.64 (Incl. of all taxes)
₹1998+ ₹359.64 GST (18%)
MRP ₹2350
SAVE 15%
7 Business Days
1 Pcs
90278090
picture_as_pdfDownload Product Leafletkeyboard_double_arrow_right
picture_as_pdfBrand Authorization Certificatekeyboard_double_arrow_right
picture_as_pdfDownload Bosch Cataloguekeyboard_double_arrow_right
picture_as_pdfBrand Authorization Certificatekeyboard_double_arrow_right
picture_as_pdfDownload Bosch Cataloguekeyboard_double_arrow_right
Highlights
The new LM320E is a lightweight and portable angle meter with a durable aluminum alloy frame. It features a high-definition color display with automatic screen rotation, supporting a full 4×90° measurement range. The device provides real-time tilt angle data and is equipped with a magnetic base for easy and stable positioning. It is widely used in engineering, construction, and mechanical installation fields.
Please Note that Product may differ eg. colour, size from the product Image displayed on website. Kindly check the specifications provided to make better purchase decision. M.R.P Prices and specifications are subject to change without notice.
Features:
- Aluminum alloy frame, lightweight & portable
- 4×90° angle measurement
- Relative/absolute measurement modes
- Multiple unit options: mm/m, in/ft, %, °
- Rechargeable 1000 mAh lithium battery
- LED-backlit rotatable screen
- Equipped with magnetic bases
Package Content:
- 1x Angle Meter
- 1x 1000mAh Lithium Battery
- 1x Type-C Cable
- 1x Gift Box
- 1x User Manual
Please Note that Product may differ eg. colour, size from the product Image displayed on website. Kindly check the specifications provided to make better purchase decision. M.R.P Prices and specifications are subject to change without notice.
Specifications
| SKU | ME.NO.DI.00083 |
|---|---|
| Product Type | Digital Angle Meter |
| Model No | LM320E |
| Rotation Range | 4° - 90° |
| Resolution | ±0.05° |
| Angle Accuracy & Repeatability | ±0.2° |
| Laser Lines | 2 Lines |
| Laser Accuracy | ±3mm / 5m |
| Laser Class | 2 |
| Laser Type | 630 - 670nm, <1mW |
| Magnetic Base | Two-sided Magnetic (Bottom & rear) |
| Unit | °; %; mm/m; in/ft. |
| Material | Al-alloy frame +ABS |
| Power Supply | 1000 mAh Lithium Battery |
| Working Temperature | 0°C ~ +50°C |
| Battery Life | 8h |
| Dimensions (mm) | 83.5 x 70 x 35.5 mm |
| Certifications | CE, RoHS |
| Language | English |
