UNI-T 6000 Count / 10000A AC True RMS Flexible Clamp Meter, UT281E+

Shop all UNI-T

SKU: ME.EL.CL.00263

Model: UT281E+

Roll over image to zoom zoom_in
  1. UNI-T 6000 Count / 10000A AC True RMS Flexible Clamp Meter, UT281E+
  2. UNI-T 6000 Count / 10000A AC True RMS Flexible Clamp Meter, UT281E+
  3. UNI-T 6000 Count / 10000A AC True RMS Flexible Clamp Meter, UT281E+

  • Product Type: Clamp Meters
  • Display Count: 6000
  • AC Current: 60.0A / 600.0A / 6000A / 10000A
See all product information chevron_right
  • receiptGST Invoice
  • headphonesCustomer Service
  • lockSecure Payments
  • policyReturns & Warranty
  • home_pinOrder Tracking
  • paymentsBuy in Installments

12537.5 (Incl. of all taxes)

10625+ ₹1912.5 GST (18%)

MRP ₹12500

SAVE 15%



7 Business Days

1 Pcs

90303390

picture_as_pdfDownload Product Leafletkeyboard_double_arrow_right
picture_as_pdfBrand Authorization Certificatekeyboard_double_arrow_right
picture_as_pdfDownload Bosch Cataloguekeyboard_double_arrow_right

Highlights

The UT281E+ True RMS Flexible Clamp Meter is a high – precision and multi – functional electrical measuring tool. It offers a current measurement range up to 10,000A, comes with a 1.1m – long flexible coil, has an overload protection circuit across the full range, and features a unique appearance design, making it suitable for a variety of application scenarios. It is widely applied in fields such as smelting, communication, manufacturing, petroleum, power, electrical engineering, and photovoltaic stations.


Features:

  • 6000 count true RMS measurement
  • Current range of 10000A (auto ranging for each level)
  • 6000A inrush current measurement
  • A flexible coil with a length of 1100mm (about 43 inches)
  • AC/DC voltage test up to 1000V
  • LCD dual - display: AC V & Hz; ACA & Hz
  • Capable of withstanding an energy impact of up to 1000V (30KVA)
  • Alarm prompts; Safety standards: IEC 61010 – 1
  • CAT III 1000V / CAT IV 600V
  • Certifications: CE, cETLus, RoHS


Package Content:

  • 1x True RMS Flexible Clamp Meter
  • 3x 1.5V AAA Batteries

Please Note that Product may differ eg. colour, size from the product Image displayed on website. Kindly check the specifications provided to make better purchase decision. M.R.P Prices and specifications are subject to change without notice.

Specifications

SKUME.EL.CL.00263
Product TypeClamp Meters
Model NoUT281E+
Display Count 6000
AC Current 60.0A / 600.0A / 6000A / 10000A
Frequency Response 45 ~ 400Hz
Resolution & Accuracy 0.01A / ±(2%+5)
Inrush Current 6000A
AC/DC Voltage 1000V ±(1.2%+3)
Resistance 60.00M Ohm: ±(1.0%+5)
Resistance Frequency 10.00Hz ~ 30.00kHz ±(0.5%+3)
Sampling Rate 3 Times/s
Power Supply 3x 1.5V AAA Batteries
Length Flexible Coil 43.30" (1100mm)
Coil Inner Dia. Radius: 6.26" (15.92cm)
Coil Dia. Ø8 mm
LCD Display Size 35 x 32 mm
Warning Indication High voltage & OL
Overvoltage Rating CAT III 1000V & CAT IV 600V
Certificates CE / ETL / ROHS
Dimensions (mm) 145 x 58 x 33 mm
