• Handles heights and overhead work with ease thanks to compact, ergonomic, low-weight design
• Overload protection, Fuse for overload, Separate switch for magnet and motor
• The weight of the current Bosch magnetic drill GBM 50-2 makes it difficult to move and use for overhead drilling
• Most users require a drilling capacity of less than 38 mm
• For the user to keep project costs under control, affordability is crucial

Benefits:

• Easy on you: 40% lighter in weight compared to GBM 50-2 for overhead application and working on heights in steel structure and towers
• Easy on the job: Great drilling capacity for at least 85% of all applications.
• Easy on your budget: Perfect combination of speed and power with a very attractive price

Metal Drilling Applications:

• General Construction
• Subway Construction
• Railway Construction
• Building Construction
• Ship Building
• Bridge Construction

FAQ:

Question	Answer
Why is the no-load speed different from the rated speed?	The tool does not feature speed control, so under load the speed will drop to about 450 rpm (no-load speed is 820 rpm and needs to be printed on the type label)
Can it be used for tapping?	The GBM38 cannot be used for tapping, since it does not feature reverse. It is only for core cutting and drilling!
How does the overload protection work?	The GBM38 features two things: A thermal overload protection, which switches the tool off, when the load is way to high (e. g. excessive drilling force over longer time). The button can be pressed in again, after the tool did cool down. Second: A (melting) fuse for short term high currents of the tool. This needs to be replaced afterward (one additional fuse in SOS).
Will it have impact with user wearing pacemaker?	Yes, it is not recommended to work with any magnetic drill when wearing a pacemaker! This is nothing specific to the GBM38, but to all magnetic core drills, since they generate a huge magnetic field to hold the tool to the workpiece firmly and safely.

What’s Included in this Package:

Magnetic Core Drill Part number: 0 601 1C5 0F0

Coolant bottle Part number: 1617S025FB

Protective guard with wing screws and washers Part number: 1617S025FM

Safety strap Part number: 1.600.A03.T7H

PPE (Safety Goggles & Hand Gloves) Part number: 1.600.A03.T7J

2.5 mm Allen keys Part number: 1.600.A03.T76

3 mm Allen keys Part number: 1.600.A03.T77

4 mm Allen keys Part number: 1.600.A03.T78

5 mm Allen keys Part number: 1.600.A03.T79

6 mm Center pin Part number: 1617S025TS

8 mm Center pin Part number: 1617S025TT

Drill chuck adaptor Weldon 19 mm (3/4”) to 1/2"-20 UNF thread

Carrying Case
