• 22 kg unit weight and optimised footprint make this the most portable saw in its class.
• Steel roll cage protects saw against jobsite drops and impacts.
• Rack and pinion fence system, front and rear fence lock and large, clear scales combine to give an extremely accurate and easy to use saw.
• Powerful 1850 Watt motor for high performance in all applications (1300 Watts 110 version for UK Only).
• Fence system provides 610 mm of rip capacity in a portable design for cutting large sheet materials to size.
• Cast table top design ensures accuracy and precision.
• Overload protection system ensures powerful performance in hard, wet or frozen woods.
• Quick bevel lock with large scale for easy, accurate adjustments.



Applications

• Power Input: 1850 Watts
• Blade Speed: 3800 rpm
• Blade Diameter: 250 mm
• Blade Bore: 30 mm
• Bevel Capacity: -3 to 48 °
• Max. Ripping Capacity [right]: 610 mm
• Max. Ripping Capacity [left]: 315 mm
• Max. Depth of Cut at 90º: 77 mm
• Max. Depth of Cut at 45º: 57 mm
• Table Size: 630 x 570 mm
• Weight: 22 kg
• Depth: 742 mm
• Length: 577 mm
• Height: 425 mm
• Sound Power Uncertainty
• 96 dB(A)
• Fitting solid wood flooring.
• General sizing of panels.
• Concrete form work.
• Sizing timber for joinery.
• Fitting out decks.



Includes

• 24 tooth SERIES 30® saw blade
• Mitre fence
• 2 blade spanners
• Parallel fence
• Dust port reducer
• Push stick.



DeWalt 2 Years Warranty:-

We believe a solid warranty package ensures the safety, reliability and service our products are meant to deliver -from the beginning to the end of every job. The DEWALT® 2 year warranty covers manufacturing defects and labour for all products.

Warranty Terms & Conditions:-

DEWALT® will repair, without charge, any defects due to defective materials or workmanship, within 2 years from date of purchase. The Warranty does not cover part failure due to excessive wear and tear or tool misuse.

Wear & Tear refers to the number of hours and/or the environment that a product has been used in; this can affect: Armature Commutators, Bearings, Switches, Beat Pieces, Clutches, Gear & Pinion, Gearcase, Brushes, Chucks, Clamshells, Cord sets, Rubber parts and Attachments (Battery, Charger, Guard, Flanges ... etc.)

The warranty does not apply where repairs have been attempted by unauthorised persons.

Issues not covered by the warranty include :

• Extreme impacts or drops
• Ingestion of foreign objects (i.e. Nails, screws ... etc)
• Using tool for non-intended application
• Any modification to the tool
• Prolonged exposure to the extreme weather conditions
• Wrong voltage
• Using incorrect accessories or attachments
• Lack of recommended service (especially hammers)
• Use of incorrect grease
• Not repaired with DEWALT® genuine parts.



Please Note that Product may differ eg. colour, size from the product Image displayed on website. Kindly check the specifications provided to make better purchase decision. M.R.P Prices and specifications are subject to change without notice.
