Insize 50 mm Optical Grating Type Linear Gauge, 7138-505
Roll over image to zoom zoom_in
- Weight: 170 Grams
- Product Type: Linear Gauge
- Range (mm): 50 mm
- Resolution: 0.5µm
- receiptGST Invoice
- headphonesCustomer Service
- lockSecure Payments
- policyReturns & Warranty
- home_pinOrder Tracking
- paymentsBuy in Installments
₹80976.32 (Incl. of all taxes)
₹68624+ ₹12352.32 GST (18%)
MRP ₹103975
SAVE 34%
3 Business Days
1 Pcs
90318000
picture_as_pdfDownload Product Leafletkeyboard_double_arrow_right
picture_as_pdfBrand Authorization Certificatekeyboard_double_arrow_right
picture_as_pdfDownload Bosch Cataloguekeyboard_double_arrow_right
picture_as_pdfBrand Authorization Certificatekeyboard_double_arrow_right
picture_as_pdfDownload Bosch Cataloguekeyboard_double_arrow_right
Highlights
- Linear gauge type: optical grating
- Dust/waterproof: IP67
- Optional accessory: display unit (code: 7131-1A, can output keyboard signal, transmit data to excel, word, txt etc., also can output serial signal and transmit data to serial communication software)
Please Note that Product may differ eg. colour, size from the product Image displayed on website. Kindly check the specifications provided to make better purchase decision.
Specifications
| SKU | ME.DI.LI.00011 |
|---|---|
| Product Type | Linear Gauge |
| Model No | 7138-505 |
| Range (mm) | 50 mm |
| Resolution | 0.5µm |
| Accuracy | ±3.5µm |
| Power Supply | DC 5V, 300mA |
| Output Signal | TTL Signal |
| Operation Environment | 0-40°C, 20~80%RH (non-condensing) |
| Storage Environment | -10~60°C, 20~80%RH (non-condensing) |
| Dimension (mm) | Ø15 x 281 mm |
