Insize Contact & Non-Contact Tachometer, 9225-405
Roll over the image to zoom in
Key Features
- Product Type: Tachometer
- Weight: 170 g
- Sampling time: 0.6s (above 100RPM)
- Power supply: 3 x AA Batteries
- Dimensions: 206 x 71 x 36 mm
ToolBuy Benefits
- Secure Payments
- Order Tracking (opens in a new tab)
₹4,916 (Incl. of all taxes)
₹4,166 + ₹750 GST (18%)
MRP was MRP ₹5,951
Save 30%
3 Business Days
1
902920
Download Product LeafletNot available
Download Insize CatalogueNot available
Download Insize CatalogueNot available
Highlights
- 2 measuring method, contact and non-contact
- Can measure rotary speed and line speed
- Automatically save the maximum value, minimum value and the last value, 500 data can be stored during continuous measurement
- Automatic power off
| Measuring method | Non-Contact | Contact | |
| Measuring range | Rotary speed | 2.5-99999RPM | 0.5-19999RPM |
| Line speed | - | 0.05-500m/min | |
| Resolution | Rotary speed | 0.1RPM (range 2.5-999.9RPM) 1RPM (range 1000~99999RPM) |
0.1RPM (range 0.5-999.9RPM) 1RPM (range 1000~19999RPM) |
| Line speed | - | 0.01m/min (range 0.05-99.99m/min) 0.1m/min (range 100~500m/min) |
|
| Accuracy | Rotary speed | +(0.05%n+1d)RPM n is rotary speed, d is resolution |
+(0.4%n+1d)RPM (n<300RPM) +(0.05%n+1d)RPM (n≥300RPM) n is rotary speed, d is resolution |
| Line speed | - | +(1%+1d)m/min d is resolution |
Standard Delivery:
| Main unit | 1 pc |
| Reflection sticker | 3 pcs |
| Wheel with 0.1m perimeter | 1 pc |
| Clamping sleeve | 1 pc |
| Cone head | 1 pc |
| Small cone head | 1 pc |
| Cone cavity head | 1 pc |
| Battery (AA) | 3 pcs |
Please Note that Product may differ eg. colour, size from the product Image displayed on website. Kindly check the specifications provided to make better purchase decision. M.R.P Prices and specifications are subject to change without notice.
Specifications
| Laser power | CLASS 3R, 3mW~4mW |
|---|---|
| Sampling time | 0.6s (above 100RPM) |
| Measuring distance | 50 - 500 mm |
| Operating teamperature | 0~40°C |
| Power supply | 3 x AA Batteries |
| Dimensions | 206 x 71 x 36 mm |
