• Delivers 50 triggered RDGS/sec via remote interface
• Period & Diode measurement
• Thermocouple Temperature & RTD measurements.
• Full math functions - dB, dBm, MX+B, ratio, %, Max/Min, null & limits.
• Optional multipoint scanner card - For internal scanning,
• Options include M3500 - Opt01, a 10-channel, general-purpose card.
• Through Microsoft Office Word & Excel for remotely storing and recalling the measured values.
• Calibration Certificate Available.
• Continuity measurement for resistance.
• Through M3500 AP software for simulating the real operation on PC.
• High noise immunity capability.
• Rack-mounted capability.
• Thermocouple / RTD Measurement
• High Accuracy - DC Voltage: ± 0.0035% of reading. AC Voltage: ± 0.06% of reading
• Display - 5 x 7 dot matrix VFD, Dual displays with three-color annunciators.
• High Speed: Both sampling rate and data rate are at 2000 readings/sec (at 4½ digit setting).
• High Capacity of Internal Data Memory: It can store up to 2000 readings in data memory
• Full-Featured Operations: There are 11 measurements and 8 math Functions.
• Temperature Measurements - The built-in function supports two measurement methods: Thermocouples and RTDs. For thermocouples, it supports up to 7 types of sensors E, J, K, N, R, S & T.
• Measurement over 20% at all ranges is allowable
• Range 750V is limited to 100KHz.

Safety:

• IEC61010-1 / EN61010-1 / UL61010-1
• E.M.C.: EN61326-2006. EN61326-2-1:2006
• Pollution Degree: 2

Package Content:

• One power line cord
• One USB cable
• Standard Test Leads
• One Software CD
• User’s manual
