Metravi 0 - 40V / 0 - 5A Programmable AC Power Supply with Adjustable Frequency (Single Output), APS-4005
Roll over image to zoom zoom_in
- Weight: 18.5 Kg
- Product Type: Power Supply
- Output Voltage: 0 - 40V
- Output Current: 0 - 5A
- Capacity: 1200VA
- receiptGST Invoice
- headphonesCustomer Service
- lockSecure Payments
- policyReturns & Warranty
- home_pinOrder Tracking
- paymentsBuy in Installments
₹90910.74 (Incl. of all taxes)
₹77043+ ₹13867.74 GST (18%)
MRP ₹113299
SAVE 32%
5 Business Days
1 Set
90308990
picture_as_pdfDownload Product Leafletkeyboard_double_arrow_right
picture_as_pdfBrand Authorization Certificatekeyboard_double_arrow_right
picture_as_pdfDownload Bosch Cataloguekeyboard_double_arrow_right
picture_as_pdfBrand Authorization Certificatekeyboard_double_arrow_right
picture_as_pdfDownload Bosch Cataloguekeyboard_double_arrow_right
Highlights
- The advanced direct digital frequency synthesizer (DDS) waveform is used to achieve high frequency stability, good continuity and accurate measurements.
- Keyboard shortcuts; 110V, 220V, 50Hz, 60Hz shortcuts selfassembly
- Key LOCK function prevents inadvertent touch
- With key lock M1, M2, M3, M4 and M5 five sets of memory can store the commonly used voltage V and frequency F, easy to recall them by one key
- Push-down infinite coding knob switch, just adjust cursor position by pressing the knob
- Four window, five digit display, display voltage V, frequency F, current I, power P, power factor PF, simultaneously and accurately
- Measuring functions: Voltage, Current, Frequency, Power, Power Factor
- Strong overload capacity: 300% overload 2s
- Intelligent analysing function: automatically judges the cause of failure and situation, as well as displays the code with alarm
- Equipped with 100% load and unload function, the voltage stabilising reaction time is within 20ms
- Input and output are isolated
- Has soft start function to avoid damage to power supply caused by instantaneous impulse current of the load (such as motor) when powering on
Please Note that Product may differ eg. colour, size from the product Image displayed on website. Kindly check the specifications provided to make better purchase decision.
Specifications
| SKU | ME.EL.PO.00093 |
|---|---|
| Product Type | Power Supply |
| Model No | APS4005 |
| Type of Product | Programmable AC Power Supply |
| Output Voltage | 0 - 40V |
| Output Current | 0 - 5A |
| Capacity | 1200VA |
| Operating Mode | SPWM (Sinusoidal Pulse width Modulation) |
| Phase | 1Ø2W |
| Voltage | 0 ~ 150VAC / 0 ~ 300VAC AUTO |
| Frequency | 45 ~ 250Hz (0.01step) |
| Maximum Current | 10A (L = 120V) / 5A (H = 240V) |
| Load Regulation | 1% |
| Waveform Distortion | 2% (low-end 120V, high-end 240V, with pure resistance load) |
| Frequency Stability | 0.01% |
| Display | Voltage / Current / Frequency / Power / Power Factor |
| Voltage Resolution | 0.01V |
| Frequency Resolution | 0.01Hz |
| Current Resolution | 0.001A |
| Storage | M1 ~ M5 (V_F_A) |
| Test Accuracy | ± 0.5% FS + 5dgt (Voltage, Electric Current & Power) / ± 0.01% FS + 5dgt (Frequency) |
| Setting Accuracy | ± 1% FS (Voltage) / ± 0.1% FS (Frequency) |
| Current Limit Setting | 0 ~ Max Current (The maximum current is: maximum capacity / 240V or P / 240) |
| Output Protection | Overcurrent, Over Temperature, Overload, Short Circuit |
| Operating Environment | 0 ~ 40°C (<80% RH) |
| Dimension (mm) | 365 x 150 x 430 mm |
