HTC 500V / 200 MOhms Range Digital Insulation Tester, DIT-90D

Name: HTC 500V / 200 MOhms Range Digital Insulation Tester, DIT-90D
Brand: HTC
SKU: ME.EL.IN.00077
Price: 1096 INR
Availability: InStock
Rating: 3.5 (55 reviews)

Shop all HTC

SKU: ME.EL.IN.00077

Model: DIT90D

Roll over image to zoom zoom_in

Visit HTC Store keyboard_double_arrow_right

Key Features

Product Type: Insulation Testers
Display: 3-1/2 Digit
Voltage: 500 V
Range: 200 MOhms

See all product information chevron_right

ToolBuy Benefits

receiptGST Invoice
headphonesCustomer Service
lockSecure Payments
policyReturns & Warranty
home_pinOrder Tracking
paymentsBuy in Installments

₹1293.28 (Incl. of all taxes)

₹1096+ ₹197.28 GST (18%)

MRP ₹1370

SAVE 20%

Dispatch: 5 Business Days

Items in Pack: 1 Set

HSN Code: 90303350

picture_as_pdfDownload Product Leafletkeyboard_double_arrow_right

picture_as_pdfBrand Authorization Certificatekeyboard_double_arrow_right

picture_as_pdfDownload Bosch Cataloguekeyboard_double_arrow_right

Highlights

3½ Digit
Optional Power Adaptor
5 Models with Various Voltage and Mohm Range
Single-Person Push Button Operation

Package Contents:

Soft Carrying Case,
Test Lead,
Manual,
6x AA 1.5V Batteries.

Functions:

Model	Rated Voltage	Range	Resolution	Accuracy	Max no. load Voltage
DIT-90A	1000 V	2000 MΩ	1 MΩ	2 mA±3%of rdg + 2 digits	±25% of rated voltage
DIT-90B	1000 V	200 MΩ	0.1 MΩ
DIT-90C	500 V	2000 MΩ	1 MΩ
DIT-90D	500 V	200 MΩ	0.1 MΩ
DIT-90E	100 V	200 MΩ	0.1 MΩ

Please Note that Product may differ eg. colour, size from the product Image displayed on website. Kindly check the specifications provided to make better purchase decision. M.R.P Prices and specifications are subject to change without notice.

Specifications

SKU	ME.EL.IN.00077
Product Type	Insulation Testers
Model No	DIT90D
Display	3-1/2 Digit
Power	AA 1.5V Batteries
Voltage	500 V
Range	200 MOhms
Dimension (HxWxD)	139 (H) x 99 (W) x 54 (D) mm
