Metravi 3-1/2 Digits / 0.1 - 20M Ohms Hand Held Digital LCR Meter, LCR-360

Shop all Metravi

SKU: ME.EL.LC.00002

Model: LCR360

Roll over image to zoom zoom_in
  1. Metravi 3-1/2 Digits / 0.1 - 20M Ohms Hand Held Digital LCR Meter, LCR-360
  2. Metravi 3-1/2 Digits / 0.1 - 20M Ohms Hand Held Digital LCR Meter, LCR-360
  3. Metravi 3-1/2 Digits / 0.1 - 20M Ohms Hand Held Digital LCR Meter, LCR-360
  4. Metravi 3-1/2 Digits / 0.1 - 20M Ohms Hand Held Digital LCR Meter, LCR-360
  5. Metravi 3-1/2 Digits / 0.1 - 20M Ohms Hand Held Digital LCR Meter, LCR-360
  6. Metravi 3-1/2 Digits / 0.1 - 20M Ohms Hand Held Digital LCR Meter, LCR-360
Visit Metravi Store keyboard_double_arrow_right
  • Weight: 0.31 Grams
  • Product Type: LCR Meter
  • Resistance Range: 200 to 20M Ohms
  • Capacitance Range: 2nF to 600µF
  • Inductance Range: 2mH to 20H
See all product information chevron_right
  • receiptGST Invoice
  • headphonesCustomer Service
  • lockSecure Payments
  • policyReturns & Warranty
  • home_pinOrder Tracking
  • paymentsBuy in Installments

₹3968.34 (Incl. of all taxes)

₹3363+ ₹605.34 GST (18%)

MRP ₹4945

SAVE 32%

5 Business Days

1 Pcs

90308990

picture_as_pdfDownload Product Leafletkeyboard_double_arrow_right
picture_as_pdfBrand Authorization Certificatekeyboard_double_arrow_right
picture_as_pdfDownload Bosch Cataloguekeyboard_double_arrow_right

Highlights

3-1/2 Digits Hand Held Digital LCR Meter, Measures Inductance from 0.001mH to 20H, Capacitance from 0.001nF to 600uF and Resistance from 0.1 to 20M.Ohms, with diode test, transistor test and audible continuity test, CE Approved.

Digital LCR Meter Model LCR-360 has a 3-1/2 digits LCD Display with steady operations, fashionable design and highly reliable hand-held measuring instrument. The LCR-360 can measure inductance, capacitance, resistance, transistor, diode and continuity buzzer test.


Features:

  • 3-1/2 Digits Large LCD Display
  • Auto Power Off
  • Over-Range Indication
  • Low Battery Indication
  • Resistance: 0 – 200 / 2k / 20k / 200k / 2M / 20MΩ.
  • Accuracy: ±0.8%
  • Capacitance: 0 – 2n / 20n / 200n / 2u / 20u / 200u / 600uF
  • Accuracy: ±1%
  • Inductance: 0 – 2m / 20m / 200m / 2 / 20H
  • Accuracy: ±2%
  • Transistor Test
  • Diode Test
  • Audible Continuity Test Facility

Please Note that Product may differ eg. colour, size from the product Image displayed on website. Kindly check the specifications provided to make better purchase decision. M.R.P Prices and specifications are subject to change without notice.

Specifications

SKUME.EL.LC.00002
Product TypeLCR Meter
Model NoLCR360
Display Backlit LCD
Colour Blue-Black
Resistance Range 200 to 20M Ohms
Capacitance Range 2nF to 600µF
Inductance Range 2mH to 20H
Accuracy ±0.8%
Power Source Battery Operated
Battery Type Alkaline
Battery Size 9V
No of Batteries 1
Sampling Time 2-3 times / sec
Certifications CE, EMC, EN 61326
