Metravi 0.2 Micro Ohm - 11 Ohms Kelvin Double Bridge With Spot Reflecting Galvanometer, KDBR
Roll over the image to zoom in
Key Features
- Product Type: Ohms Meter
- Range: 0.2 micro ohm to 11 ohms
- Coil Resistance: 100 ohms approx
- CDR: 800 ohms approx
ToolBuy Benefits
- Secure Payments
- Order Tracking (opens in a new tab)
₹86,659 (Incl. of all taxes)
₹73,440 + ₹13,219 GST (18%)
MRP was MRP ₹1,08,000
Save 32%
5 Business Days
1
90303390
Download Product LeafletNot available
Download Metravi CatalogueNot available
Download Metravi CatalogueNot available
Highlights
Kelvin Double bridge, with spot reflecting galvanometer, High Current DC power supply and wooden stand for specimen
Features:
- Suitable for the use of wires and cable manufacturers and Transformer industry
- Extensively used for finding the resistance of transformer winding, contact resistance of relays etc.
- Measures in the range of 0.2 Micro ohms to 11 Ohms
- Measurement Ranges: 2 Milliohms to 11 Ohms, 0.2Milli Ohms to 1.1 Ohms, 20 Micro Ohms to 11 Ohms, 2 Micro Ohms to 0.11 Ohms and 0.2 Micro Ohms to 0.0011 Ohms
- Max Current 10A intermittent and 5A continuous
- Battery Reversing Switch provided to reverse the current in the bridge to eliminate thermal effect
- Complete with Spot Reflecting Galvanometer, Heavy Duty DC Current Source, Conductivity Attachment
Please Note that Product may differ eg. colour, size from the product Image displayed on website. Kindly check the specifications provided to make better purchase decision. M.R.P Prices and specifications are subject to change without notice.
Specifications
| Range | 0.2 micro ohm to 11 ohms |
|---|---|
| Accuracy | ± 0.05 ± 1 small division of the slidewire |
| Coil Resistance | 100 ohms approx |
| CDR | 800 ohms approx |
| Time Period | 2 seconds approx. |
| Input Voltage | 230 Volts A.C. Mains at 50 Hz |
| D.C. Output | Approximately 0 to 10V |
| Max. Current | 10 amperes intermittant and 5 amperes continuous |
| Sensitivity | 0.05 microampers per mm or 5 microvolts per mm |
