Insize 30000 Max. Reading DC Resistance Tester, 9655-RM03
Roll over the image to zoom in
Key Features
- Product Type: Ohms Meter
- Weight: 3.5 kg
- Max. Reading: 30000
- Basic Accuracy: 0.1%
ToolBuy Benefits
- Secure Payments
- Order Tracking (opens in a new tab)
₹74,867 (Incl. of all taxes)
₹63,447 + ₹11,420 GST (18%)
MRP was MRP ₹93,304
Save 32%
5 Business Days
1
–
Download Product LeafletNot available
Download Insize CatalogueNot available
Download Insize CatalogueNot available
Highlights
- Short-circuit zero function
- Temperature compensation function
- Comparator: pass or fail judge
Technical Data:
| Function | Range | Resolution | Accuracy of the Medium Speed Test | Accuracy of Slow Speed Test | Test Current |
| Resistance Test | 30mΩ | 0.001mΩ | ±(0.2%+5d) | ±(0.1%+3d) | 1A |
| 300mΩ | 0.01mΩ | ±(0.2%+3d) | ±(0.1%+2d) | 1A | |
| 3Ω | 0.0001Ω | 100mA | |||
| 30Ω | 0.001Ω | 10mA | |||
| 300Ω | 0.01Ω | 1mA | |||
| 3kΩ | 0.0001KΩ | 1mA | |||
| 30KΩ | 0.001kΩ | 100µA |
Package Content:
- 1x DC Resistance Tester
- 1x RS232 Cable
- 1x Temperature Probe
- 1x Test Clip
Please Note that Product may differ eg. colour, size from the product Image displayed on website. Kindly check the specifications provided to make better purchase decision. M.R.P Prices and specifications are subject to change without notice.
Specifications
| Max. Reading | 30000 |
|---|---|
| Basic Accuracy | 0.1% |
| Range Mode | Auto Range, Manual Range & Nominal Range |
| Test Speed | 2t/s (Slow) & 12t/s (Medium) |
| Trigger | Internal, Manual & Bus Trigger |
| Power Supply | 200V±10% (AC), 50/60 Hz |
| Dimension (LxWxH) | 349.5 x 264 x 107 mm |
